Sensory Swing Installation Guide (Step-by-step + Printable Checklist)

Creating a sensory swing space at home can be very helpful, but safety comes first. Follow this guide to make sure your installation is secure and reliable. If you are unsure at any point, talk with a qualified professional.

Skip to steps Open checklist No-mount options Swings hub Sensory Swings for Adults Pod swings Compression swings Platform swings Sensory chairs

Before you begin: safety basics

  • Weight capacity. Choose hardware and anchors with a working load that is well above the expected user weight. Plan for dynamic forces (aim for 2-3x the user weight).
  • Mounting surface. Install only into solid wood joists/beams or concrete. Never rely on drywall alone.
  • Clearance zone. Leave at least 3-4 feet of unobstructed space around and above the swing. Keep walls, doors, and furniture out of the swing path.
  • Supervision. An adult should supervise at all times. Set clear rules: one rider (unless rated), feet first, slow and steady, ask to start/stop.

Tools and hardware you will need

  • Sensory swing
  • Ceiling mount or swing hanger plate with rated mounting hardware
  • Swivel for 360-degree rotation (optional, if rotation is desired)
  • Locking carabiners (2-3)
  • Adjustable straps or daisy chains
  • Stud finder, drill, drill bits (pilot and mounting size), ladder
  • Measuring tape, pencil, safety glasses, gloves
  • Wrench or socket set (as required by your hardware)

Step-by-step installation

  1. Select the spot. Choose an open area with a safe landing surface and enough ceiling height for the swing arc.
  2. Locate the joist. Use a stud finder and mark both edges of a joist. Drill a small test hole (about 1/16 in) to confirm solid wood.
  3. Drill pilot holes. Follow your hardware instructions and drill pilot holes slightly smaller than the lag screw size.
  4. Secure the mount. Fasten the swing hanger plate with lag screws (wood) or use rated masonry anchors for concrete. Drive screws to the manufacturer torque spec.
  5. Attach hardware. Clip in the swivel (if used) and swing with locking carabiners. Verify gates close completely.
  6. Load test. Gradually apply weight and test the assembly before full use. Listen for creaks and watch for movement.

Advanced mounting options

If your joist location is not ideal or access is limited, consider these approaches:

  • Cleat/backer board. Secure a 2×6 across multiple joists to spread the load. Mount the hanger to the board.
  • Blocking from above. Add blocking between joists from the attic to create a stronger load path.
  • Load spreader. Use two eye bolts with a short chain or rigid bar to reduce side loading at a single point.

Final checks and maintenance

  • Recheck all hardware after the first week of use, then every 3-6 months.
  • Inspect for loose bolts, cracked wood, frayed fabric or straps, and worn carabiners/swivels.
  • Keep the area under and around the swing clear and use a mat or rug where helpful.
  • Stop use immediately if anything looks damaged or unstable.

Sensory Swing Installation Checklist

Planning and site

  • 3-4 ft clearance around and above the swing
  • Mounting surface confirmed: wood joist/beam or concrete
  • Working load of hardware comfortably exceeds user weight (plan 2-3x)
  • Ceiling height measured for a safe arc and head clearance

Hardware and tools

  • Ceiling plate/swing hanger with rated hardware
  • Swivel (if rotation is desired)
  • Locking carabiners and adjustable straps/daisy chains
  • Stud finder, drill, pilot and mounting bits, ladder
  • Tape measure, pencil, safety glasses, gloves

Installation steps

  • Mark joist edges; drill a small test hole to confirm solid wood
  • Drill pilot holes per hardware instructions
  • Mount hanger with lag screws (wood) or rated anchors (concrete)
  • Attach swivel and swing with locking carabiners
  • Gradually load test and listen for movement or noise

Advanced options (if needed)

  • 2×6 backer board spanning multiple joists
  • Attic blocking between joists
  • Dual eye bolts with a short chain or rigid bar

Final checks and maintenance

  • Re-inspect after first week; then every 3-6 months
  • No loose bolts, cracks, sharp edges, or worn parts
  • Straps/swivel clean and moving freely
  • Stop use and reassess if instability appears

Download the printable checklist (PDF)

Prefer a PDF you can keep on your phone or toolbox?

Click here to download the Sensory Swing Installation Checklist (PDF)

Frequently asked questions

What joist size is acceptable for mounting?

Most residential joists are 2×8 or larger. Always confirm your joist size, species, and condition. If in doubt, consult a contractor. Never mount into drywall only.

What drill bit size should I use for pilot holes?

Follow the hardware instructions. A common rule is to use a pilot bit slightly smaller than the lag screw core diameter so the threads can bite into wood.

Can I mount into a metal I-beam?

Yes, but this requires hardware designed for steel and may need professional installation. In many cases it is easier to use a free-standing frame instead.

Do I need a swivel?

Only if you want rotation. A rated swivel reduces rope twist and spreads forces during turning. It does not replace proper mounting or supervision.

How high should I hang the swing?

Set a height where the rider can touch feet to the floor to stop. For platform swings, add extra clearance for the full arc. Adjust using daisy chains/straps.

What is the difference between working load and breaking strength?

The working load is the safe everyday limit. Breaking strength is the failure threshold during testing. Choose hardware where the working load comfortably exceeds your total expected load.

Is outdoor installation OK?

Use weather-appropriate hardware and protect fabric from sun and rain when not in use. Inspect more frequently outdoors due to corrosion and UV exposure.

What if I feel movement in the mount after installation?

Stop use immediately. Recheck attachment points, pilot hole sizing, and anchor type. Consider upgrading hardware or using a backer board across multiple joists.

Are doorway bars safe?

Use only bars designed and rated for dynamic load, and follow the manufacturer limits. Keep doors closed and the area clear while in use.

Any tips to reduce noise?

Use rubber washers or bushings where appropriate, check for metal-on-metal contact, and keep swivels and carabiners clean and properly aligned.

When should I talk to a professional?

If you are unsure about the structure, if the rider seeks intense spinning, or if you notice signs of dysregulation after use, consult a contractor or an occupational therapist.
